Unmanned systems

From the VT-4 VTOL reconnaissance aircraft to the FP-18, KW-E and KW-G precision-engagement systems, for defence, security and civil operators.

  • 01Fixed-wing VTOL ISR UAV
    SkyCopes VT-4 fixed-wing VTOL UAV, front view with its EO/IR/LRF gimbal camera

    VT-4

    Payload
    5kg
    Flight time
    3 / 8h
    Range
    100km
    Details: VT-4
  • 02Multirotor UAS with target engagement
    SkyCopes FP-18 multirotor with its gimbal camera and payload

    FP-18

    Payload
    10kg
    Flight time
    20min
    Range
    15km
    Details: FP-18
  • 03Compact fixed-wing UAS with target engagement
    SkyCopes KW-E compact fixed-wing unmanned aircraft in black

    KW-E

    Payload
    2.5kg
    Flight time
    1–1.5h
    Range
    100km
    Details: KW-E
  • 04Long-range fixed-wing UAS with target engagement
    SkyCopes KW-G long-range fixed-wing unmanned aircraft with a pusher propeller

    KW-G

    Payload
    10kg
    Flight time
    5h
    Range
    500km
    Details: KW-G

Compare the systems

From long-endurance ISR to precision engagement: the published figures side by side.

Specification 01VT-402FP-1803KW-E04KW-G
Maximum take-off weight 40kg 25kg 10kg 50kg
Payload 5kg 10kg 2.5kg 10kg
Flight time 3 / 8h Type 1 electric / Type 2 gasoline 20min 1–1.5h 5h
Operational range — 15km 100km 500km
Communication range 100km 15km 100km 100km
Flight speed 80–85km/h 90–120km/h 90–120km/h 90–120km/h
Wingspan 4m — 1.5m 2m
Length 2m — 1.2m 2.2m
Payload camera EO/IR/LRF all-in-one EO/IR, changeable EO/IR EO/IR
Maximum flight height 3,000mAll systems
Operational temperature −10 to +60°CAll systems

Figures as published in the SkyCopes product brochure. A dash means the figure is not published for that system.
